This series of surge protector is suitable for AC 50/60Hz, 380V and the following TT, TT, TN-C-S power supply system, can be used as LPZ1, LPZ2 area boundary at the equal potential connection, it involves the basis of IEC61643-1, GB18802.1, the shell is involved in the installation of 35mm electrical guide rail, The product has a built-in failure detachment device. When the surge protector fails due to over-current overheating and breakdown, the failure detachment device can automatically detangle it from the point network. At the same time, the visible alarm indicator module changes from green (normal) to red (fault).
1. The protector unit can be replaced without replacing the base;
2, can withstand up to 100KA (8/20μs) lightning current impact;
3. The corresponding action time is less than 25 nanoseconds:
4. The color of the visual window indicates the working status of the protection. Green (normal) becomes red (fault).
Model: the NRM - old D40
Rated operating voltage Un(V) : 220/380
Maximum continuous operating voltage Uc(V) : 420
Nominal discharge current In(KA) : 10
Maximum discharge current Imax(KA) : 20
Voltage protection level Up(KV) : ≤1.5
Corresponding time (ns) : 25
Minimum cross-sectional area of access wire L/N(mm²) : 2.5
Minimum cross-sectional area PE(mm²) : 4
Fuse or circuit breaker type selection (A) : 32
Installation: 35mm standard guide rail
Shell material: UL94-V0 grade flame retardant plastic
